Features
- Compliant with LoRaWAN 1.0.3
- Support Packet Forward/Basic Station Mode
- Support Spectral Scan & Listen Before Talk (LBT)
- Various Internet connection: Ethernet, Wi-Fi or 3G/4G backhaul
- Firmware updates automatically over-the-air
Power Supply
- DC 12 V/2 A-Power Adaptor
- DC 10~30 V 3-Pin Connector Power supply
- Passive PoE 10~30 V
GPS
- GPS + GLONASS, L1C/Aband (optional for time-stamping)(*)
Wi-Fi
- 802.11b/g/n, 1x1, 2.4GHz (optional for backhaul)(*)
4G/LTE
- Quectel PCIe module (LTE Cat 4 or Cat M1/NB2(*))
Interfaces
- WAN RJ45 10/100Mbps (w/ passive PoE capability)
- Reset button
- SIM card slot (2FF)
- DC jack in
- LED indicators
Antennas
- 1 external LoRa
- 1 external 4G
- 1 external Wi-Fi
- 1 external GPS
Dimensions
-
120mm x 136mm x 35mm
-
4.72 inches x 5.35 inches x 1.38 inches
Weight
- 0.40 kg
- 0.88 lbs
Security
- AES 128
Certifications
- FCC / IC / CE
- LoRaWAN 1.0.3
